The desirable temperature for swimming pools is 30oC.
The pump removes the latent heat from the surrounding atmosphere transferring it to the water . This means that 80% of the heating requirements are obtained from nature and there is only the need for 20% of electrial input making these pumps the most reliable and efficient way of heating water.


Electronic control panel: automatically allows you to achieve optimum performance throughout the full range of operating conditions, making the Vulcan-HP® swimming pool heat pump the most efficient pool heater available. The control panel features a digital display, programmable thermostat and control indicator lights.

Evaporator air coil: oversized dual row, fabricated from copper tubes and coated aluminium fins (copper fins optional).

Cabinet: 304 stainless steel, casing designed to blend in perfectly with your pool landscape.

Fan motor: high performance, that allows for maximum efficiency and quiet operation.

Heat exchanger: high performance pure titanium tubing optimises heat transfer.

Compressor: ultra efficient Copeland Scroll.

Refrigerant: Standard R22 (HCFC), Optional R407C

Water connections: 50mm Coupled unions.


Model Voltage Power input Running current Heat output Height Width Length Weight
V06H 220/240V 1.5 kW 7.2 A 6 kW 680mm 480mm 720mm 45 kg
V08H 220/240V 1.1 kW 4.7 A 8 kW 680mm 480mm 720mm 52 kg
V10H 220/240V 1.7 kW 7.4 A 10 kW 760mm 570mm 850mm 75 kg
V12H 220/240V 2.0 kW 10.0 A 12 kW 760mm 570mm 850mm 85 kg
V15H 220/240V 2.5 kW 12.5 A 15 kW 860mm 570mm 850mm 94 kg
V18H 220/240V 3.0 kW 14.5 A 18 kW 780mm 770mm 860mm 105 kg
V20H 220/240V 3.6 kW 16.5 A 20 kW 780mm 770mm 860mm 110 kg
V25H 380/420V 4.3 kW 7.2 A 25 kW 920mm 820mm 1040mm 120 kg
V30H 380/420V 5.1 kW 8.0 A 30 kW 920mm 820mm 1040mm 130 kg
V40H 380/420V 6.7 kW 9.7 A 40 kW 920mm 820mm 1040mm 150 kg
* All units can be manufactured to operate at 60Hz and 480volts
